Intel R1304WFTYSR Server

Key Features Manufacturer Part Number: R1304WFTYSR Number of Processors Supported: 2 Processor Supported: Xeon Platinum Xeon Gold Xeon Silver Xeon Bronze 64-bit Processing: Yes Chipset Manufacturer: Intel Chipset Model: C624 Maximum Memory: 7.50 TB Memory Technology: DDR4 SDRAM Memory Standard: DDR4-2933/PC4-23466 Number of Total Memory Slots: 24 Intel Optane Memory Ready: Yes Controller Type: 12Gb/s SAS RAID Supported: Yes Ethernet Technology: 10 Gigabit Ethernet Number of Total Expansion Bays: 4 Number of 3.5″ Bays: 4 Total Number of USB Ports: 5 Number of SATA Interfaces: 10 Number of Power Supplies Installed: 1 Maximum Power Supply Wattage: 1100 W Form Factor: Rack-mountable Rack Height: 1U Height: 1.7″ Width: 16.9″ Depth: 28″ Package Contents: Server System R1304WFTYSR 1 x 1U chassis with Quick Reference Label affixed to top cover 1 x Intel® Server Board S2600WFTR (dual 10 GbE LAN) 2 x Riser card assembly with 1 slot PCIe x16 riser card F1UL16RISER3 4 x 3.5″ hot-swap drive bays with drive carriers and drive blanks. Includes: 1 x 12 Gb SAS backplane FR1304S3HSBP 4 x 3.5″ hot swap drive tool less carriers FXX35HSCAR2 1 x Pre-installed standard control panel assembly (board only FXXFPANEL2) 1 x Pre-installed front I/O panel assembly (1 x VGA and 2 x USB) 1 x 150 mm backplane I2C cable 1 x 850 mm mini SAS HD cable AXXCBL850HDHRT 1 x 350 mm backplane power cable 1 x SATA optical drive power cable 300 mm 1 x SATA optical drive bay mounting kit 1 x Air duct 6 x Dual rotor system fan FR1UFAN10PW 1 x 1100W power supply module AXX1100PCRPS 2 x CPU heat sinks, 39 fin passive 2 x CPU heat sink “No CPU” label inserts 2 x Standard CPU Carriers Limited Warranty: 3 Year General Information Manufacturer: Intel Corporation Manufacturer Part Number: R1304WFTYSR Manufacturer Website Address: http://www.intel.com Brand Name: Intel Product Line: Server System Product Model: R1304WFTYSR Product Name: Server System R1304WFTYSR Packaged Quantity: 1 Product Type: Barebone System Processor & Chipset Number of Processors Supported: 2 Processor Supported: Xeon Platinum Xeon Gold Xeon Silver Xeon Bronze 64-bit Processing: Yes Chipset Manufacturer: Intel Chipset Model: C624 Memory Maximum Memory: 7.50 TB Memory Technology: DDR4 SDRAM Memory Standard: DDR4-2933/PC4-23466 Number of Total Memory Slots: 24 Intel Optane Memory Ready: Yes Controllers Controller Type: 12Gb/s SAS RAID Supported: Yes Network & Communication Ethernet Technology: 10 Gigabit Ethernet I/O Expansions Number of Total Expansion Bays: 4 Number of 3.5″ Bays: 4 Interfaces/Ports Total Number of USB Ports: 5 Number of SATA Interfaces: 10 Power Description Number of Power Supplies Installed: 1 Maximum Power Supply Wattage: 1100 W Physical Characteristics Form Factor: Rack-mountable Rack Height: 1U Height: 1.7″ Width: 16.9″ Depth: 28″ Miscellaneous Package Contents: Server System R1304WFTYSR 1 x 1U chassis with Quick Reference Label affixed to top cover 1 x Intel® Server Board S2600WFTR (dual 10 GbE LAN) 2 x Riser card assembly with 1 slot PCIe x16 riser card F1UL16RISER3 4 x 3.5″ hot-swap drive bays with drive carriers and drive blanks. Includes: 1 x 12 Gb SAS backplane FR1304S3HSBP 4 x 3.5″ hot swap drive tool less carriers FXX35HSCAR2 1 x Pre-installed standard control panel assembly (board only FXXFPANEL2) 1 x Pre-installed front I/O panel assembly (1 x VGA and 2 x USB) 1 x 150 mm backplane I2C cable 1 x 850 mm mini SAS HD cable AXXCBL850HDHRT 1 x 350 mm backplane power cable 1 x SATA optical drive power cable 300 mm 1 x SATA optical drive bay mounting kit 1 x Air duct 6 x Dual rotor system fan FR1UFAN10PW 1 x 1100W power supply module AXX1100PCRPS 2 x CPU heat sinks, 39 fin passive 2 x CPU heat sink “No CPU” label inserts 2 x Standard CPU Carriers Warranty Limited Warranty: 3 Year Additional information Weight 22 lbs Dimensions 10 × 39 × 23 in Condition New UPC 735858406833 MPN R1304WFTYSR Product Type Barebone System 64-bit Processing Yes Number of SATA 10 Number of Total Memory 24 Number of Processors 2 Number of 3.5″ Bays 4 Product Family Server System Total Number of USB 5 Memory Standard DDR4-2933/PC4-23466 Memory Technology DDR4 SDRAM Rack Height 1U Brand Intel Form Factor Rack-mountable Processor Supported Xeon Bronze Controller Type 12Gb/s SAS Maximum Memory 7.50 TB
